HFV-4010P LED Industrial Radiography Film Viewer Non Destructive Testing Equipment

Name: HFV4010P LED Industrial Radiography Film Viewer Non Destructive Testing Equipment
Brand: HUATEC
Price: 2450 USD

Quality HFV-4010P LED Industrial Radiography Film Viewer Non Destructive Testing Equipment wholesale

Brand Name : HUATEC

Model Number : HFV-4010P

Certification : CE

Place of Origin : China

MOQ : 1 SET

Price : USD2450-USD3050/SET

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10 Sets/Month

Delivery Time : 7-10 working days after receipt of your payment

Packaging Details : Outer carton packaging

Adapter Input voltage : 85-264VAC/47-60Hz Power: 200W

Maximum Light Intensity : >100,000 Cd/㎡

Film density : >4.0D According to the inspection report

Surface temperature : <18°Celsius Continuous operation for 24 hours)

Uniform Viewing Area : 95% Full Screen

Dimmer Control : 0% to 100% continuous

Control mode : Manual + Foot-switch

Cooling Method : Forced air cooling

Viewer window : 400mm*10mm (L*W)

Viewing-mask window : 24x10cm, 24x6cm, 40x6cm (L*W) optional

Power : 200W

Contact Now

HFV-4010P LED Industrial Radiographic Film Viewer

Features:

New design: Highly reliable and innovative, optimized right-side Panel control

Viewing area: 400x100mm

Easily View＞4. 0 Density

Pure White LED Light

50,000 Hour Lamp Life

Low Power Consumption

Fan cooling

Control mode: Manual+Foot-switch

Design: Modern, Stylish and Simple

Mask size: 24x10cm, 24x6cm, 40x6cm optional

Specifications:

Adapter Input voltage	85-264VAC/47-60Hz Power: 200W
Maximum Light Intensity	>100,000 Cd/㎡
Film density	>4.0D According to the inspection report
Surface temperature	<18°Celsius Continuous operation for 24 hours)
Uniform Viewing Area	95% Full Screen
Dimmer Control	0% to 100% continuous
Control mode	Manual + Foot-switch
Cooling Method	Forced air cooling
Dimensions	610x155x60+50mm (LWH)
Viewer window	400mm10mm (LW)
Viewing-mask window	24x10cm, 24x6cm, 40x6cm (L*W) optional
Power	200W
Weight	5.8 KG

Package Contents:

LED viewer with densitometer HFV-4010P 1pc

Foot switch 1pc

AC power cord 1pc

Viewing mask 1pc

Magnetic film holder 2pcs

Magnetic ruler 1pc

User's manual 1pc

Calibration certificate 1pc

Trouble shooting Cause of the fault:

The power light is not on Elimination method: Check the power switch (8) to see if it is on the position of the foot switch, if is, should use in the foot switch mode. Check the lightness adjustment knob on the right-side control penal to see if it is on the minimum position, it is, should turn it to the proper lightness in the clockwise.
